תרכובת לכבלים
בית > Hoses > תרכובות PVC > תרכובת לכבלים
טרפלקס מציעה קו של RoHS חוטי ויניל וכבלים. תרכובות PVC שאינן תואמות פתלטים ו-REACH זמינות גם עבור יישומים שחייבים לעמוד בתקנים הרגולטוריים הבינלאומיים המחמירים ביותר. ניתן להשתמש בתרכובות החוטים והכבלים של Terraflex ביישומים כגון:
- כבלים חשמליים בטמפרטורה גבוהה (בהתאם לתקני CEI, BS, VDE, UL וכו')
- כבלים לרכב (בהתאם ל-ISO 6722)
- חוט בנייה
מידות
132 NAT
Application: wire insulationProperties | Test Method | Units | Standard |
---|---|---|---|
Density | ASTM D792 | gr/cm3 | 1.42-1.46 |
Hardness | ASTM D 2240 | SHORE A | 85-91 |
Tensile Strength | ASTM D 638 | n/mm2 | > 16 |
Elongation | ASTM D 638 | % | > 245 |
Thermal Stability | 200°C | minutes | > 60 |
137 NAT
Application: High Temp. Sheath and InsulationStandards: BS 6746 Type 4, UL 1581, UL 83-105C
Properties | Test Method | Units | Standard |
---|---|---|---|
Density | ASTM D792 | gr/cm3 | 1.34-1.40 |
Hardness | ASTM D 2240 | SHORE A | 80-86 |
Tensile Strength | ASTM D 638 | n/mm2 | > 15 |
Elongation | ASTM D 638 | % | > 280 |
Thermal Stability | 200°C | minutes | > 60 |
Flame Retardant | N/A |
145 WT
Application: Flexible Cable SheathProperties | Test Method | Units | Standard |
---|---|---|---|
Density | ASTM D792 | gr/cm3 | 1.36-1.44 |
Hardness | ASTM D 2240 | SHORE A | 68-78 |
Tensile Strength | ASTM D 638 | n/mm2 | > 12 |
Elongation | ASTM D 638 | % | > 280 |
Thermal Stability | 200°C | minutes | > 60 |
175 NAT (TRC)
Application: Flexible Sheath (RT1+SDI FIX+N2XY Flex) ROHS approvedStandards: IS 473 TH4, AS3808 V90/5, V90 (AS3147)
Properties | Test Method | Units | Standard |
---|---|---|---|
Density | ASTM D792 | gr/cm3 | 1.30-1.35 |
Hardness | ASTM D 2240 | SHORE A | 64-72 |
Tensile Strength | ASTM D 638 | n/mm2 | > 12 |
Elongation | ASTM D 638 | % | > 330 |
Thermal Stability | 200°C | minutes | > 60 |
Pressure Test | IEC 811 | %- 90°C | 50 |
Electrical resistance 20°C 90°C | AS 1660 | Gohmxm Gohmxm | 40 0.002 |
714 NAT
Application: Telephone insulationStandards: BS 6746 Type 2, DIN/VDE 0207 YI3, REA 220- insulation, UL 1581- TYPE 75C
Properties | Test Method | Units | Standard |
---|---|---|---|
Density | ASTM D792 | gr/cm3 | 1.31-1.35 |
Hardness | ASTM D 2240 | SHORE A | 91-97 |
Tensile Strength | ASTM D 638 | n/mm2 | > 22.5 |
Elongation | ASTM D 638 | % | > 200 |
Thermal Stability | 200°C | minutes | > 60 |
Flame retardant | UL 94 | V0 |
726 FRUV
Application: High Temp. insulation and sheath, flame retardant, UV StabilizedStandards: BS 6746 Type 5, DIN/VDE 0207 Y18, YM4.
MIL-W-16878, UL 1581- TYPE 105C
Properties | Test Method | Units | Standard |
---|---|---|---|
Density | ASTM D792 | gr/cm3 | 1.30-1.34 |
Hardness | ASTM D 2240 | SHORE A | 90-96 |
Tensile Strength | ASTM D 638 | n/mm2 | > 19 |
Elongation | ASTM D 638 | % | > 200 |
Thermal Stability | 200°C | minutes | > 120 |
Flame retardant | UL 94 | V0 |
728 NAT
Application: Flexible insulation for wireProperties | Test Method | Units | Standard |
---|---|---|---|
Density | ASTM D792 | gr/cm3 | 1.50-1.54 |
Hardness | ASTM D 2240 | SHORE A | 82-92 |
Tensile Strength | ASTM D 638 | n/mm2 | > 12.6 |
Elongation | ASTM D 638 | % | > 200 |
Thermal Stability | 200°C | minutes | > 60 |
730 FRUV
Application: General purpose insulation and sheathing, flame retardant and weather resistanceStandards: BS 6746 T11, T12, TM1, TM2, Type 9.
DIN/VDE 0207 Y11, Y12, YM1, YM2, YM5.
IEC 60502 ST-2
Properties | Test Method | Units | Standard |
---|---|---|---|
Density | ASTM D792 | gr/cm3 | 1.42-1.46 |
Hardness | ASTM D 2240 | SHORE A | 85-91 |
Tensile Strength | ASTM D 638 | n/mm2 | > 15 |
Elongation | ASTM D 638 | % | > 228 |
Thermal Stability | 200°C | minutes | > 80 |
Flame retardant | IEEE 383 | PASS | |
L.O.I | % | 26.7 |
730 GN ST-2
Application: Flexible sheathing N2XY cableStandard: IEC 60502 ST-2
Properties | Test Method | Units | Standard |
---|---|---|---|
Density | ASTM D792 | gr/cm3 | 1.40-1.44 |
Hardness | ASTM D 2240 | SHORE A | 86-92 |
Tensile Strength | ASTM D 638 | n/mm2 | > 15 |
Elongation | ASTM D 638 | % | > 230 |
Thermal Stability | 200°C | minutes | > 80 |
739 NAT
Application: Filling substanceProperties | Test Method | Units | Standard |
---|---|---|---|
Density | ASTM D792 | gr/cm3 | 1.74-1.80 |
Thermal Stability | 200°C | minutes | > 60 |
